Unmatched Efficiency, Unwavering Reliability: The Champion of Concrete Delivery
The Foton 8 CBM Concrete Mixer Truck is the undisputed champion of high-volume concrete production. This robust and feature-rich vehicle is meticulously engineered for heavy-duty construction projects, ensuring efficient and high-quality concrete delivery on every job.
Built to Conquer, Engineered to Perform
- 8X4 Drive Train: Provides exceptional traction and control, navigating even the most challenging terrains with ease.
- Spacious Body Dimensions (9.605 x 2.5 x 3.825 meters): Maximizes concrete volume, optimizing productivity on large-scale construction sites.
Powerhouse Performance, Eco-Friendly Operations
- Dongfeng Cummins ISDe270 40 Engine: This 6.7L powerhouse delivers a remarkable 270 horsepower (198 kW) for efficient and reliable concrete mixing.
- Common Rail + SCR Technology: Enhances fuel efficiency and reduces emissions, minimizing environmental impact.
- EURO II-VI Emission Standards: Compliance with regulations for a cleaner and more sustainable future.
Advanced Mixing Technology, Superior Efficiency
- CSCTRUCK VanTruckTrailer Upper Installation: Ensures high-quality and durable construction for reliable operation.
- Large 8m³ Mixing Tank: Accommodates substantial concrete quantities, maximizing production output.
- Slump Range of 80-220mm: Offers versatility to meet diverse concrete consistency requirements.
- Rapid Loading/Unloading (≥3m³/min and ≥2m³/min): Optimizes concrete handling and keeps project timelines on track.
- Low Residual Rate of Discharge (0.6%): Minimizes concrete waste and ensures maximum material utilization.
- Air Pressure Water Supply: Offers precise and controlled water supply for consistent concrete mixing.
Operator Comfort, Unmatched Durability
- ETX-2420 Cab: Provides a comfortable and ergonomic workspace for long work days.
- Reliable Foton Chassis Series: Renowned for its robust construction, guaranteeing a safe and reliable driving experience even on uneven terrain.
- 12 Tires: Contribute to superior traction and exceptional load-bearing capacity for heavy-duty applications.
- Total Mass of 31 Tons: Offers substantial load-carrying capacity, ideal for large-scale construction projects.
Experience the unmatched efficiency and unwavering reliability of the Foton 8 CBM Concrete Mixer Truck. Dominate large-scale concrete production and ensure high-quality concrete delivery on every project.
SPECIFICATIONS:
| Parameter | Value |
|---|---|
| Drive Type | 8X4 |
| Body Dimensions | 9.605 x 2.5 x 3.825 meters |
| Front Overhang/Rear Overhang | – |
| Wheelbase | 1860 + 3050 + 1300 mm |
| Rated Load | – |
| Vehicle Weight | – |
| Maximum Speed | 85 km/h |
| Front Wheel Track/Rear Wheel Track | – |
| Engine Parameters | |
| Engine Model | Dongfeng Cummins ISDe270 40 |
| Fuel Type | Diesel |
| Number of Cylinders | 6 cylinders |
| Maximum Output Power | 198 kW |
| Maximum Horsepower | 270 horsepower |
| Displacement | 6.7L |
| Emission Standard | EURO II, EURO III, EURO IV, EURO V, EURO VI |
| Engine Type | Common Rail + SCR |
| Rated Speed | 2500 RPM |
| Upper Installation Parameters | |
| Vehicle Type | Concrete Mixer Truck |
| Upper Installation Brand | CSCTRUCK VanTruckTrailer |
| Vehicle Production Location | – |
| Mixing Tank Capacity | 8m³ |
| Mixing Drum Geometric Capacity | – |
| Slump | 80-220mm |
| Loading Speed | ≥3m³/min |
| Unloading Speed | ≥2m³/min |
| Residual Rate of Discharge | 0.6% |
| Water Supply Method | Air Pressure |
| Other | |
| Total Mass | 31 tons |
| Cab Parameters | |
| Cab | ETX-2420 |
| Chassis Series | Foton |
| Number of Tires | 12 |
